A carton flow quote can look complete while leaving out the cartons and work pattern that determine whether the lanes actually function. Track type, rack dimensions and a headline capacity tell only part of the story. Before ordering, define what moves through each lane, who loads and picks it, and how the system will be maintained. This buying checklist focuses on specification evidence rather than a generic promise of faster picking.
List each candidate SKU, case footprint, height, minimum and maximum weight, bottom material, rigidity, daily picks and replenishment quantity. Include the packaging as it is actually presented to the lane: tape, straps, labels, open tops and variable fill levels can all change travel behavior. Identify which SKUs are likely to change package size within the planning period.
A dedicated lane has a space cost even when it is empty. Rank SKUs by pick frequency and forecast stability, then decide how many facings each needs. Compare the number of cases per lane with the quantity delivered in a normal replenishment trip. If a lane holds too little, staff refill it constantly; if it holds too much, valuable pick-face space may be tied up in reserve stock.
Ask for a representative trial with the lightest and heaviest cases, including imperfect but acceptable cartons. Observe travel from the rear to the front at the proposed slope and depth. Check whether a case skews, stalls, accelerates too sharply, catches a label or strikes the stop. Record the result for each package family rather than approving a track from one ideal sample.
The Carton flow rack system combines tracks, guides, stops and supporting frame. Specify lane width, pitch, track support spacing and the accepted carton range together. Confirm rated loads at lane, shelf and complete-bay levels, including any point load concentration. A carton may roll well yet exceed a structural limit when a full lane is replenished.
Sketch the rear loading aisle, front pick aisle, replenishment source and completed-order exit. Separate traffic only if the building can support the circulation. Check reach heights, sight lines, case presentation and the effort needed to lift a full carton into the highest lane. A mathematically dense layout is a poor purchase if operators must stretch or rehandle cases to use it.
Confirm how a lane is cleared when a damaged carton stops moving. Front stops and tracks must be accessible for inspection and replacement without creating an unsafe shortcut. Provide labels that remain readable after replenishment and a rule for handling returned or short-dated stock. These details affect day-to-day capacity as much as lane count does.
For variable or slow-moving cases, Wide span shelving may allow more flexible slotting. Selective pallet racking can carry pallet reserve stock feeding the pick area. Compare these zones by travel, replenishment effort, occupied floor area and expected change in SKU mix. Do not compare a flow-rack price with bare shelf steel while excluding guides, stops, guards, installation and aisle changes.
Ask which cartons were tested and what lane slope and depth the quotation assumes.
Request drawings showing clear access, aisle widths, obstructions and each pick-face height.
Confirm load ratings, anchorage, floor requirements, guards and site-specific installation responsibilities.
Clarify replacement parts, maintenance access, labeling and procedures for SKU changes.
A supplier needs more than a total number of cartons. Provide a matrix that links each SKU to case dimensions, weight range, case-bottom type, expected daily picks, peak picks and replenishment frequency. Indicate whether the case is picked whole or opened for piece picking. A few very fast products may need more than one facing, while dozens of slow products can consume excessive space if each receives a permanent lane. The allocation should be revisited when the assortment changes, rather than treating the first slotting plan as permanent.
Estimate the required active stock per facing from demand during the replenishment interval, then add a justified buffer. Convert that quantity into lane length using the measured carton footprint and spacing. If replenishment arrives on pallets, account for how many cases can be moved in a practical trip and where the pallet can be staged without blocking a pick aisle. A lane that accepts only part of a normal delivery may leave awkward residual cases elsewhere. The goal is a coherent stock flow, not the largest number of theoretical lanes on a drawing.
A test protocol should state which samples are used, how many cartons are placed in a lane, what slope and track arrangement are fitted, and what counts as acceptable travel. Include full and partially filled cases when both occur in practice. Observe the first carton, the middle of a loaded lane and the last carton approaching the stop. Note skewing, stalls, uncontrolled speed and damage to labels or box corners. A short demonstration with a clean, rigid empty box does not establish reliable performance across the real packaging range.
Ask who signs off on the trial and how an unsuitable SKU will be handled. A track may pass for most cases but fail for a soft-bottom carton or a new supplier’s packaging. The decision could be to modify the guide, use a different track, add a suitable tote or keep that SKU on static shelving. Documenting the exception prevents a later purchase decision from silently assuming universal compatibility. If packaging changes after installation, the revised case should be tested against the same acceptance criteria before it enters the lane.
A capacity statement needs a defined load arrangement. Ask whether the quoted lane load is based on an evenly distributed series of cases, and obtain the level and bay ratings as well. Confirm the rack height, beam or track support details, anchorage and any required protection. Provide floor information and building drawings showing columns, doors, sprinkler clearances, services and changes in level. Site-specific requirements and local approvals should be checked by the responsible qualified parties; a catalog description does not settle them.
The pick face must connect to the rest of the operation. Check whether carts, conveyors or order containers fit the aisle and whether the operator can identify each lane without reaching across another product. At the rear, allow enough room to bring cartons to the loading height and remove packaging waste. Plan where empty reserve pallets go. If picking and replenishment routes cross at a narrow point, the theoretical advantage of separate faces may disappear during peak work. Review the proposed installation with both shift supervisors and equipment users.
A purchasing comparison should identify tracks, wheels or rollers, guides, front stops, labels, guards and spare parts by function and quantity. Clarify which components can be adjusted and what tools or downtime a change requires. Ask for the inspection points and the procedure for removing a damaged carton or replacing a damaged track. A low initial price can be misleading if common service parts are omitted or if a lane must be dismantled extensively for a small repair. Record the supplier’s assumptions about installation labor and site readiness.
Change control matters because the SKU profile rarely stays fixed. Set a rule for reassigning a lane when a case size or weight changes, including rechecking guide spacing, travel and rated loading. Keep original drawings and updated configuration records accessible to operators and maintenance staff. If a track is moved to a new shelf position, verify the resulting clearances and ergonomic reach. A design that can be changed in principle is not automatically simple to change safely in a live warehouse.
Before comparing proposals, record the present pick rate, picker travel, replenishment effort, packaging damage and stockout events for the candidate SKUs. Model the same workload with the proposed flow area, including the labor to refill it and handle exceptions. Compare installed cost and usable pick faces rather than price per piece of steel. Avoid treating a published maximum labor saving as a forecast for your building. A pilot with representative cartons can establish a more credible range of outcomes and reveal whether another shelf layout would solve the same problem more simply.
Request at least two design options if the data support them: for example, more shallow lanes with frequent replenishment and fewer deep lanes with greater active stock. The alternatives expose a trade-off between pick-face width, stock depth and replenishment trips. Include projected SKU growth and a plan for products that leave the flow zone. This gives the purchasing team a reasoned basis for selection and a clear record of what must be retested if the operation changes.
Agree on acceptance criteria before installation begins. The criteria can include tested carton families, lane travel without stalls or damage, clear and usable pick heights, labels that remain visible, and documented load information. Specify how many representative lanes will be checked and how defects will be recorded and corrected. A handover should include drawings reflecting the installed configuration, operating guidance and the components needed for routine maintenance. Without that agreed process, a disagreement about whether the system performs as quoted may be hard to resolve after the warehouse has been rearranged.
Ask the supplier to separate assumptions from confirmed requirements in the proposal. An assumed carton size, idealized floor condition or unspecified lift method can materially change the final price and performance. Mark who supplies the test cartons, who prepares the floor, who installs protection and who trains the operators. If the scope changes, update the drawing, cost and acceptance test together. This avoids comparing one complete offer with another that silently excludes essential work.
The best buying decision starts with actual cartons and real pick data. Test travel, size lanes around replenishment quantities, and compare the complete installed workflow with static alternatives. A quotation should make its assumptions visible enough to review when products change. Shanghai Shibang Storage Rack Co., Ltd. manufactures carton flow racks; the appropriate configuration still depends on confirmed packaging, structural loads and site circulation.
Use the smallest, largest, lightest and heaviest actual cartons, plus acceptable packaging variations that might affect the base or edges.
One clearly identified SKU per lane is the straightforward starting rule; any sharing needs a controlled changeover and reliable separation.
No. Excessive speed can damage cartons or overload a front stop, so slope must be validated with the real weight range.
Compare tested carton ranges, rated loads, drawings, accessories, installation scope, maintenance provisions and assumptions about the floor and workflow.
